Saturday, January 31, 2009

2nd gear "removed"


Progress is slow at the moment. Amazing how much time earning a living and raising a family can take. Oh and I joined an online Sim racing league (again) . That didn't help. My EV project is a hobby anyway. The sooner it's done the sooner I'll be thinking of some other project.

Not much to report except I did grind the teeth off 2nd gear. Didn't really take that long. Used a thin cutting wheel on my angle grinder to cut off most of the teeth. Kind of like cutting the kernals of corn of corn on the cob. Then I took a grinding wheel to it make it mostly round. Here's a before and after picture. Took about 30 min. Wife said the sparks were more impressive than the firework fountains we usually buy for the 4th of july

Saturday, January 10, 2009

Trans is damaged


EV construction has been slowed for some Tramission issues. I've gotten the transmission apart. The trans that "worked fine just needed a rebuild" is missing many teeth on 2nd gear.

This trans is basically beyond repair. I wish it had been 1st gear as I probaby don't need 1st gear. The way it was the trans sounded like it was crunching gravel. No suprize there. For now I'm thinking I'll grind off ALL the 2nd gear teeth and just go without a 2nd gear. May not need it so much. I can get another transmission later. We'll see.

I think finish my adapter plate and then decide.

Sunday, January 4, 2009


UPDATE: When I spun the trans with the motor the transmission sounded like it was full of rocks. I was told it made a "rattle" when I bought it. I figured it just needed new bearings but this was a much more than a rattlle. Either way the trans needed to come apart so apart it came.

Turns out there are many teeth broken off 2nd gear. Too bad it wasn't first gear as it that doesn't seem to be needed in and EV. I'll spend some more time practicing rebuilding this transmission as with a car of this age the next trans I buy will likely need some rebuilding too.

Friday, January 2, 2009

Mate motor to trans

Did a little more work. Mated the trans to the motor. Have some more trimming to do on the adapter plate (or plates depending on how you look at it). I mounted one plate to the motor and one to the trans. With the trans setting on the motor and the input shaft engaged with the clutch I spun the motor and centered or checked to ensure it was centered prior to pining the 2 plates together. One thing I found was the clutch alignment tool would align the clutch disc so the trans could be installed but it was not truely centered. So I used the dial indicator to center the clutch plate prior to putting on the pressure plate. This turned out perfectly.

Couple of pictures.
The taper lock installed on the motor



Transmission on top of the motor.
